Модель продукта SUPU
45065X-030
Шаг изделия
5.0
Количество подключений
X
Способ подключения
Spring cage connection
Класс защиты
IP20
Рабочий температурный диапазон
-40~+105℃
Номинальный ток (IEC)
12A
Номинальное напряжение (IEC)
320V
Номинальное импульсное напряжение
4.0KV 4.0KV 4.0KV
Сечение жесткого провода
0.2-2.5mm²
Сечение гибкого провода
0.2-2.5mm²
Сечение гибкого провода с изолированной гильзой
0.2-2.5mm²
Длина зачистки изоляции
8~9mm
Заказной номер
45065X-030
